Specification:

• Faster Connections: Speeds up to 1200 Mbps—867 Mbps on 5 GHz and 300 Mbps on 2.4 GHz.*

• Boosted Seamless Coverage: Achieve seamless whole home coverage with a clearer and stronger WiFi signal.

• One Unified Network: Multiple units form a whole-home network that auto-selects the best connection as you move around your home.

• Enhanced Security: WPA3 encryption, Multi-SSID, and Parental Controls provide personalized and safer online experience.

• EasyMesh Compatible: Provides whole home WiFi coverage with standard mesh technology.

• Easy Setup: Set up your mesh WiFi in minutes with the powerful Aginet app.

• Remote Management: TAUC cloud management, TR-098, TR-181, TR-111, and TR-143 are supported.

HARDWARE FEATURESExternal Power Supply12 V ⎓ 1.0 AInterface3× Gigabit Ports

*Per Unit
1 Port supports WAN/LAN auto-sensingButtonReset Button
WPS ButtonDimensions ( W x D x H )3.9 x 3.9 x 3.5 in
(100 x 100 x 89.5 mm)WIRELESS FEATURESFrequency2.4 GHz and 5 GHzSignal RateAC1200
5 GHz: 867 Mbps (802.11ac)
2.4 GHz: 300 Mbps (802.11n)Transmit PowerFCC: <30 dBm (2.4 GHz), <30 dBm (5 GHz)
CE: <20 dBm (2.4 GHz), <23 dBm (5 GHz)Wireless SecurityWPA-PSK/WPA2-PSK/WPA3 Personal encryptionsWireless StandardsWi-Fi 5
IEEE 802.11 a/n/ac 5 GHz
IEEE 802.11 b/g/n 2.4 GHzMulti-SSID2× 5 GHz Multi-SSID
2× 2.4 GHz Multi-SSIDSOFTWARE FEATURESWAN TypeDynamic IP/Static IP/PPPoEQuality of ServiceWMMFirewall SecuritySPI FirewallManagementLocal Management, TAUC Cloud Management, TR-069(TR-098/TR-181), TR-111, TR-143Advanced FeaturesParental Controls, QoS (Quality of Service), Address Reservation, Port Forwarding, WiFi ScheduleProtocolsIPv4
IPv6Working ModesRouter Mode
Access Point ModeOTHERSPackage ContentsHC220-G5 (2-pack)
2 HC220-G5 Units
1 RJ45 Ethernet Cable
2 Power Adapters
1 Quick Installation Guide

HC220-G5 (1-pack)
1 HC220-G5 Unit
1 RJ45 Ethernet Cable
1 Power Adapter
1 Quick Installation GuideCertificationsCE, FCC, Wi-Fi CERTIFIED™, Wi-Fi CERTIFIED EasyMesh™EnvironmentOperating Temperature: 0℃–40℃ (32℉ –104℉)
Storage Temperature: -40℃–60℃ (-40℉ –140℉)
Operating Humidity: 10%–90% non-condensing
Storage Humidity: 5%–90% non-condensingSmartphone/Tablet RequirementsAndroid 4.4 or later
iOS 9.0 or later
