Specification:

Wiegand Card Readers 125kHz EM or 13.56MHz IC card reader Wiegand interface

Parameters

• Read RangeKRxxx-E: Up to 10CM
  KRxxx-M: Up to 5CM

• Reading Time≤ 300ms

• Input PortExternal LED Control
  External Buzzer Control

• MaterialABS + PC with texture

• Output FormatKRxxx-E: 26bit Wiegand (Default)
  KRxxx-M: 34bit Wiegand (Default)

• Power SupplyDC 6-14V / Max.70mA

• LEDRed and Green LEDs

• Operating Temperature-20°C to 65°C (-10° to +70°C)

• Operating Humidity10% to 90% relative humidity non-condensing

• Ingress Protection RatingKR600-E/M: IP65
  KR601-E/M: IP65
  KR602-E/M: IP64
